High port count, 12-48 VDC powered, UL listed
RLH industrial switches are engineered to provide reliable network performance in harsh environments. The 16+2 Gigabit SFP switch is an unmanaged switch that accepts both copper and fiber Gigabit Ethernet access. Dual rate industrial grade SFPs are recommended.
It is environmentally hardened to operate over a wide temperature range, which makes it ideal for locations that are found in industrial locations, such as in factory, utility, equipment closets, and other uncontrolled environments.
Our industrial switches are engineered with robust features and construction to meet the demands of a variety of applications, and are an ideal solution for a wide range of utility and automation environments.
Features
- 16 Gigabit Ethernet ports
- 2 Dual Rate SFP slots: 100Mbps & 1Gbps
- Wide operating temperature range of -40°C to 75°C (-40°F to 167°F)
- 12~48VDC dual redundant power inputs
- Power fault alarm relay
- Rugged IP30 housing, DIN rail & wall mountable
- UL, CE, and FCC certification
- TAA and NDAA compliant
- 5 Year Warranty
Please see the product documentation for the complete list of specifications
Ethernet Ports:
(16) 10/100/1000 Mbps
(2) SFP Slots, Accepts 100 or 1000 Mbps speed transceivers
Power Input:
12~48VDC redundant power inputs (6 position pluggable terminal block)
Max. Power Consumption:
15.4 Watts Full Loading
Operating Temperature:
-40°C to 75°C (-40°F to 167°F)
Construction:
Powder coated steel IP30 housing
Installation:
Standard DIN rail (TS-35) or wall mount
*Wall mount brackets included
Case Dimensions:
2.6” (W) x 3.9” (D) x 5.6” (H), (67mm x 99mm x 142mm)
*Not including connectors or DIN bracket
Compliance:
CE, FCC Class A, UL 61010-1 and UL 61010-2-201, RoHS and REACH
MTBF:
731,474 hrs.
Warranty:
5 Years
Product Information
CAD Files
ETH-162G-1
For product questions, volume pricing and/or delivery outside of the US and Canada, please contact sales.
Ordering
16+2 Unmanaged 10/100/1G SFP Industrial Switch
| Short description | Part number | Price | |
|---|---|---|---|
| 16+2 Unmanaged 10/100/1G Industrial Ethernet Switch, SFP(100/1G) ports 12-48VDC | ETH-162G-1 | $890.00 |
