Managed Industrial Layer 2 Gigabit Switch

Temperature Icon

Fiber Optic Icon

Gbit Ethernet IconWeb Interface IconSFP Optics IconDIN Icon

Request a Quote
Features
  • Hardened design has a wide operating temperature range: -40 to +167F (-40 to + 75 C)
  • Dual Rate SFP ports - 100Mbps & 1Gbps
  • 5 Ports of Gigabit Ethernet
  • 9.6K Bytes Jumbo Frame Support
  • Auto MDI/MDI-X
  • Store-and-forward switching architecture
  • Rugged case rated to IP-30
  • Redundant power inputs with built-in alarm
  • 2kV surge protection
  • DIN rail & wall mountable

Managed Features

  • Configuration via Web, Serial, Telnet, & SSH
  • Supports SNMPv3
  • Supports IEEE 802.1q Vlans
  • Port Mirroring, Control, & Monitoring
Overview

RLH managed industrial switches are engineered to provide reliable network performance in harsh environments. The 5+1 Managed Gigabit SFP switch provides both copper and fiber Gigabit Ethernet access. This environmentally hardened layer 2 switch is manageable and offers a wide array of configuration and monitoring options.

Our feature rich industrial switch meets the demands of a variety of applications, and are an ideal solution for a wide range of utility and automation environments.

Specifications

For a comprehensive review of the product specs, please see the Data Sheet, or feel free to contact us with any questions.


Construction:
Powder coated IP30 steel housing


Ethernet Ports:
(5) 10/100/1000 Mbps


SFP Sides:
(1) Dual Rate SFP
Supports both 100 &1000 Mbps speed modules


Ethernet Interface:
Supports Jumbo Frames, Auto MDI/MDI-X, Auto Negotiation


Management:
Layer 2 - See User Guide for complete management details


Mounting Style:
Standard DIN rail (TS-35) or wall mount
Wall mount brackets included


Dimensions:
1.81” (W) x 3.90” (D) x 5.59” (H), (46mm x 99mm x 142mm)
Not including connectors or DIN bracket


Operating Temperature:
-40°F to 167°F (-40°C to 75°C)


Fault Output:
1 Relay output rated for 24VDC @ 1 Amp


Power Protection:
Over Current, Power Reversal, Polarity Protection


Powering Requirement:
12~55VDC redundant power inputs


Safety:
FCC Class A, CE

Diagrams
5+1 Managed Gbit SFP Switch Dimensions

5+1 Managed Gbit SFP Switch Dimensions

Downloads

Download the RLH Data Sheet

Download the Software Manual

Download the RLH DXF File

Download the Step File

Ordering

Please submit a quote request or contact your RLH sales representative for pricing and delivery information.

Numbers

ETH-51GM-1
